Chlorine washing and bubble washing dual purpose machine
-
Chlorine washing and bubble washing dual purpose machine
-
American chlorine washing machine
main features
Adopting a horizontal drum type, both the inner and outer cylinders are made of high-quality stainless steel plates, which are flat, bright, corrosion-resistant, and have little wear and no damage to the fabric. The machine has a long service life;
The inner cylinder door cover is equipped with a stainless steel safety locking mechanism, and the outer cylinder door cover is equipped with an electrical interlock device, ensuring safe and reliable operation;
Adopting triangular tape transmission, it has low vibration, smooth operation, and durability.
Type | Maximum washing capacity | drum(mm) | (kw)power | r/min | (Mpa) steam pressure | (mm) overall dimensions |
GX10 | 10 | φ480*600 | 0.55 | 46 | 0.4-0.6 | 1030*730*1030 |
15 | 0.75 | 46 | 0.4-0.6 | 1100*800*1140 | ||
GX20 | 20 | φ600*700 | 0.75 | 42 | 0.4-0.6 | 1120*860*1170 |
GX30 | 30 | φ660*800 | 1.1 | 36 | 0.4-0.6 | 1520*1100*1300 |
GX50 | 50 | φ800*980 | 1.5 | 36 | 0.4-0.6 | 1750*1200*1500 |
GX70 | 70 | φ950*1220 | 2.2 | 34 | 0.4-0.6 | 2050*1300*1700 |
GX100 | 100 | φ960*1420 | 3 | 34 | 0.4-0.6 | 2300*1300*1800 |
GX150 | 150 | φ1060*1650 | 4 | 33 | 0.4-0.6 | 2500*1400*1800 |
GX200 | 200 | φ1080*2000 | 5.5 | 32 | 0.4-0.6 | 2900*1400*1900 |
GX250 | 250 | φ1200*2280 | 7.5 | 30 | 0.4-0.6 | 3200*1820*2100 |
GX300 | 300 | φ1300*2280 | 7.5 | 28 | 0.4-0.6 | 3200*1930*2200 |
GX400 | 400 | φ1220*3360 | 11 | 28 | 0.4-0.6 | 4300*1900*2100 |
